Author Topic: 10' axial flux home made windmill  (Read 32866 times)

0 Members and 1 Guest are viewing this topic.

oldculett

  • Newbie
  • *
  • Posts: 29
10' axial flux home made windmill
« on: April 04, 2009, 09:45:33 PM »
First off, I would like to thank all of the posters here, even the newbies that asked odd questions because I gained very much from the answers.  I'd also like to thank the sponsors of the board for putting it all together, and for their new book.


The reason for getting involved in building a wind generator is I'm building a cabin on some remote property and the power company wanted $84,000 to run the line.  So, here I am.


And now for the monologue.  It is mostly a Hugh Piggott machine with a little otherpower influence.  It has coils: 75 turns, 2 in hand, #17 AWG, 9 coils on 12 inch 3/8 plate for 3 phase.  Magnets are 2 inch x 1 inch x 1/2 inch, N40, supposedly for 24 volt.


The hub I used was from a small station wagon. I just walked around the junkyard till I found one I could use.





I built a coilwinder as seen in the postings and books. Added a counter so the wind count would be on the mark.






Here's the coils after they were wound.





Here they are laid out.





Here they are pasted up with strips of fiberglass.  All I could get was the none-woven fiberglass and it wasn't very strong and it came apart easily so if you have a choice, I would recommend getting the woven stuff.





Here's the stater mold with 3 coats of wax on top of 2 coats of linseed oil.



My mold was made out of 3/4 inch veneer covered chipboard and I was afraid it might flex or bow, so I put some heavy boards across to make sure it was flat and clamped it well.



Here is the casting ready to be popped out of the mold.  It came out very easily.  I was surprised.  With a slight slap on the back with my hand and it came out.



I had some finning around the edges but it all came loose also, because I had waxed everything many times.



The finning cut off quite easily so was not a big problem.  When I got close to the casting, I just ground it away with a small die grinder.



I had the rotor plates cut by a local welding shop being my hub had 5 holes, and also I wanted to have some holes cut that matched some holes in the hub for ventilation.  I don't know if that will actually work, but I'll give it a try.  On the indexing plate that I got from Otherpower, there was no allowance for other than a 4-hole spindle, so it took me awhile to figure out where to put some holes so I could key it to the rotors to make sure my north - south magnet match would be.





These are a couple shots of the main frame.  It's basically just pieces of iron from my scrap pile.  Instead of welding two angle irons together as Hugh does, I used a piece of channel iron that was wide enough to accommodate my hub.



I put a small extra brace on the tail for a little more support and I just like the looks of it better.



This shows the one rotor that has the vent holes in it.  This is the one that will bolt tight to the hub so they will be the only way in for extra air.





A couple more shots of the main frame and the tail attached.



This shows the rotor with the band.  I cut the bands from a piece of sheet stainless steel that I had, as they don't use stainless steel banding around here.  It wasn't exactly straight but I think it worked out okay.  I cleaned the plates with lacquer thinner before I put the magnets on.  I also had lightly sanded the plates hoping the resin would stick better.





The cast poured into the rotor.  I think the stainless steel rim made it a lot easier than building a mold to hold it all, and, of course, I always make a mess, but I try to make it easy to clean up with the newspaper.  After the casting had cured for several days, I painted the magnet side with the super duty epoxy paint hoping to keep the moisture away from the magnets.



The base rotor on with the vent holes lined up with the holes in the hub.





Here's the first shot of the base rotor and the stator installed.





Here's the second rotor on and a view of the side showing that the magnets stick up above the rim slightly.  I thought this might work like fan blades and help pull air through to keep things cool.



I had two extra plates made to put on both sides of the blades to help support everything.  I stuck one of these on the bolts just before I tightened everything for the last time to make sure that the bolts stayed in alignment.





No one carries cedar around here except for fencing material which was very poor quality.  I finally found some posts that were approximately four inches square that I picked through and found fairly straight grained ones that I ripped in half, and then edge planed and glued back together.  I found that I could get two five-foot blades out of three strips and I probably could have made longer blades if I had needed them without any more waste.  After I glued them up, I ran them through my planer to make sure they were all the same thickness and flat.







I did most of the main roughing out with a hand power planer.  It worked quite well but you need to be careful on cutting too much off.





It only took me a couple days to get the carved blades done, and then I fit checked the pieces to make sure everything fit together.



After putting the front and rear ground plates on the blade, I had drilled a 1/8 inch hole in the exact center.  I hung this from the rafters of my garage with a wire and used fishing weights to figure out where the balance weight needed to be.  It all seemed to work out quite well.  The blades that I carved ranged in weight from 3 pounds 7 oz., to 3 pounds 9 oz., so I didn't think this was too bad for seat of the pants hand planed work.



I was trying to figure out how to seal the top of the pivot and make a usable power splice box and this is what I came up with.  So far, it looks like it's going to work okay.



Well, a lot of people have written that linseed oil was the best coating so I put approximately 8 coats, maybe more, on them.  They seem pretty good.  Hopefully, they will last.  I hadn't really thought about the cedar being very fragile but in just handling the blades and bumping the trailing edge on the workbench, I got a couple of dings in them.



I have built a temporary tower (about 20' tall) that I will be mounting the generator on for a test run in my back yard.  Hope to have it up within a few days.  Will post an update when I get it in the air.

« Last Edit: April 04, 2009, 09:45:33 PM by (unknown) »

halfcrazy

  • Sr. Member
  • ****
  • Posts: 387
Re: 10' axial flux home made windmill
« Reply #1 on: April 04, 2009, 04:50:57 PM »
Looks great it is way to much fun isnt it. the blades look real good i can only hope my 17 footer's blades come out that good.
« Last Edit: April 04, 2009, 04:50:57 PM by halfcrazy »

TomW

  • Super Hero Member Plus
  • *******
  • Posts: 5130
  • Country: us
Re: 10' axial flux home made windmill
« Reply #2 on: April 04, 2009, 09:04:53 PM »
oldcullet;


Nicely done! And nicely documented with photos.


Thanks for sharing.


Do you want me to remove your other post in the main forum? Or put a link to this in that one to keep the discussion in one place?


Just let me know here.


Tom

« Last Edit: April 04, 2009, 09:04:53 PM by TomW »

oldculett

  • Newbie
  • *
  • Posts: 29
move story
« Reply #3 on: April 05, 2009, 12:23:49 AM »
Yes please remove the story in wind and put a link to here. Thanks  Oldculett
« Last Edit: April 05, 2009, 12:23:49 AM by oldculett »

frackers

  • Sr. Member
  • ****
  • Posts: 401
  • Country: nz
  • Is it finished yet?
Re: 10' axial flux home made windmill
« Reply #4 on: April 05, 2009, 02:39:08 AM »
Excellent work - I really like the power splice box and the blade balancing detail. I balanced mine after I had the blades mounted and the bearing was a bit stiff when I first did it. After 6 months of flying it had slackened off enough to get it right and remove the shimmy!!
« Last Edit: April 05, 2009, 02:39:08 AM by frackers »
Robin Down Under (Or Are You Up Over)

keithturtle

  • Full Member
  • ***
  • Posts: 204
  • Country: us
  • Things that fly
    • aftertherapture
Re: 10' axial flux home made windmill
« Reply #5 on: April 05, 2009, 11:21:37 PM »
Excellent work, and it's good to see your determination pay off.   Hope it flies well


Turtle

« Last Edit: April 05, 2009, 11:21:37 PM by keithturtle »
soli deo gloria

luv2weld

  • Sr. Member
  • ****
  • Posts: 308
Re: 10' axial flux home made windmill
« Reply #6 on: April 06, 2009, 07:21:25 AM »
Really nice work!!

And a darned good job of documenting it!!

Your blades are gorgeous. In one photo the blade tips are

rounded and in the next photo, they look to be squared.

Is this an illusion??? If not, did you round them to

keep the noise down???


Ralph

« Last Edit: April 06, 2009, 07:21:25 AM by luv2weld »
The best way to "kill time" is to work it to death!

oldculett

  • Newbie
  • *
  • Posts: 29
Re: 10' axial flux home made windmill
« Reply #7 on: April 06, 2009, 09:01:42 AM »
They are round, that photo just does not show it. Oldculett
« Last Edit: April 06, 2009, 09:01:42 AM by oldculett »

Ungrounded Lightning Rod

  • SuperHero Member
  • ******
  • Posts: 2781
Re: 10' axial flux home made windmill
« Reply #8 on: April 06, 2009, 07:22:31 PM »
Sweet!


Several comments:


 1) Air really wants big holes and more of them to get any decent flow through the disks.


 2) The arrangement of air holes unbalances the rotor.  Shoulda' had five, not three.  Not fatal.  But you'll have to balance the rotor and blades as a unit.  (Mount your blades so the heaviest part is near the singleton hole - and the extra hub weight from the two missing holes - to minimize the tuning weights you need.)  The stationary part of the genny won't be balanced so you'll need to spin it (in a calm area or inside, with the axis horizontal) and see which blade/side stops pointed down.  Spin it in both directions to compensate for friction and average the downmost points.  When it's balanced it will stop randomly.  If you don't get it close to balance it will wig-wag when running (putting wear on the bearings, mainly the yaw bearing) and will be harder for the wind to start.


 3) I don't see any mechanism for jacking the rotor down.  How did you do that?  (How will you get it off if you need to adjust the gap?)


 4) You'll get a bit more out of the blades if you make the ends sharp, i.e. the end of the blade thins down to a knife-edge in the last inch or so rather than being rounded.  It throws the tip vortex out - i.e. reduces the tendency of the air to run around the end of the blade from the high- to the low-pressure side and depower the last few inches of the tip, by making it jet off the tip so the blade has moved on by the time it gets turned around.  Inch-for-inch the outermost part of the blade has the most swept area and thus the most potential power.

« Last Edit: April 06, 2009, 07:22:31 PM by Ungrounded Lightning Rod »

oldculett

  • Newbie
  • *
  • Posts: 29
Re: 10' axial flux home made windmill
« Reply #9 on: April 07, 2009, 08:35:40 AM »
Thanks for the comments.


  1.  The holes in the hub dictated the size of the holes in the bottom rotor.  It was about 1 inch each.
  2.  At the time, I chose the hub, I never thought about the balancing.  I just figured that GM probably had put them in the right place.  As it turned out, they must have because the hub was not unbalanced.  I don't know if it was counter-weighted in the thickness of the casting or what, but it was balanced. I balanced the blade off of the generator but after I put it together, it would not seek any other spot than where it happened to be.  I had planned to let it run for a little while and check for balance again.
  3. Now, the holes in the rotor, I only put the three 1-inch holes in the base rotor not the outside rotor.  If you look on the photo of the generator with the alignment plate on the bolts, you'll see that I have jacking screw holes in the outside rotor.  I did put a large center hole in the outside rotor and the blade plate is spaced out one nut width to let air in that side.
  4.  I had not known about sharpening the ends of the blades.  When I take it down to move to the permanent site, I will try to modify them.


I appreciate any and all comments.  Thank you.  Oldculett
« Last Edit: April 07, 2009, 08:35:40 AM by oldculett »

customman

  • Newbie
  • *
  • Posts: 1
Re: 10' axial flux home made windmill
« Reply #10 on: October 24, 2009, 10:57:49 PM »
ok, i love this post!  it has turned me into a wind junkie.  My parents own property that is ontop a naked hill, and receives wind 24/7/365.  I am going to make one of these mills, my next question is how would you grid tie this?  what are the next necessary steps... i have been reading up and the aurora looks like it is the brains.  also i have read that some sort of RPM limiter is needed "brake".  no batteries will be used, i am looking for direct grid tie only.  any help anyone has to offer, or links to posts that would outline the proper process would be greatly appreciated.  Thanks.
« Last Edit: October 24, 2009, 10:57:49 PM by customman »

oldculett

  • Newbie
  • *
  • Posts: 29
Re: 10' axial flux home made windmill
« Reply #11 on: November 09, 2009, 06:08:46 PM »
I tried to answer this before but for some reason, it would not post.  But, I just ran a test and it's posted so I will try again.


Grid tyeing a system is much more complicated than what I have done.  My property does not have the grid available so I am strictly wind gennie with batteries.  From what I understand, there is many rules and many dollar controllers to make that happen, and the coils and such must be wound for that purpose.  If you read more on this site, I'm sure you'll find out what you need if you truly want to go grid tied.  Oldcullett

« Last Edit: November 09, 2009, 06:08:46 PM by oldculett »

oldculett

  • Newbie
  • *
  • Posts: 29
Re: 10' axial flux home made windmill
« Reply #12 on: March 28, 2011, 09:28:46 PM »
I have built another wind mill much like this one I will post a store of it soon.
Oldculett
